Go Concurrency 2.3 - Patterns and Idioms | Pipelines

October 1, 2023

Pipelines

Pipelines are a tool to abstract away logic that doesn’t matter to immediate work in hand. It constitutes of primarily three parts, input, perform an operation, and output. Each such operation can be referred as a stage, and a pipeline can have more than one stage. Each stage is supposed to be isolated from the other, and therefore can be individually modified, leveraged, removed or be used to limit the rate of flow of data. Consider these a specific derivative of functional programming.

Two important attributes for a pipeline stage

The stage consumes and returns the same type.
The stage should be reified i.e. developers can work directly with the types related to it.

Batch processing pipelines

Pipelines that accept and return batch of data.

package main

import (
	"fmt"
)

func multiply(numberStream []int, multiplier int) []int {
	result := make([]int, len(numberStream))
	for i, v := range numberStream {
		result[i] = v * multiplier
	}

	return result
}

func add(numberStream []int, additive int) []int {
	result := make([]int, len(numberStream))
	for i, v := range numberStream {
		result[i] = v + additive
	}

	return result
}

func main() {
	input := []int{1, 2, 3, 4, 5}

	for _, v := range add(multiply(input, 2), 1) {
		fmt.Println(v)
	}
}

Playground -

The business logic has been kept simple to focus on the design pattern.
This kind of processing is called as batch processing, since the processing happens in batch. It has it’s own pros and cons.
Notice how at every stage we have to create another slice of equal length to input slice. This means at any point of a stage, we will need double the memory.
In this approach, the next stage starts only when all elements are done processing by the first stage.

Stream processing pipelines

Pipelines that receive and return one element at a time.

package main

import (
	"fmt"
)

func multiply(input, multiplier int) int {
	return input * multiplier
}

func add(input, additive int) int {
	return input + additive
}

func main() {
	input := []int{1, 2, 3, 4, 5}

	for _, v := range input {
		fmt.Println(add(multiply(v, 2), 1))
	}
}

Playground

Notice how each stage operates on a single element, removing the need of additional memory.
In this approach as soon an element is processed by one stage, it enters the other.

Channels and pipelines

Channels fit perfectly to be used along with pipeline design pattern. They allow read or write of values of same kind onto channels. This makes them highly composable following the DRY principle.
